INVT Goodrive300 Series Operation Manual page 128

Goodrive300 Series VFD
Function
Name
code
AI3 input
P17.21
voltage
HDI input
P17.22
frequency
P17.23 PID reference
P17.24 PID feedback
Power factor
P17.25
of the motor
Current
P17.26
running time
Simple PLC
and the
P17.27 current step of
the multi-step
speed
ASR controller
P17.28
output
Magnetic pole
P17.29
angle of SM
Phase
P17.30 compensation
of SM
High-frequenc
P17.31
superimposed
current of SM
Magnetic flux
P17.32
linkage
Exciting
P17.33 current
reference
P17.34 Torque current Display the torque current reference in the vector
Detailed instruction of parameters
Display analog AI2 input signal.
Range: -10.00–10.00V
Display HDI input frequency.
Range: 0.000–50.000kHz
Display PID given value.
Range: -100.0–100.0%
Display PID response value.
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display the current running time of the VFD.
Range:0–65535m
Display simple PLC and the current stage of the
multi-step speed.
Range: 0–15
The percentage of the rated torque of the
corresponding motor, display ASR controller
output.
Range: -300.0%–300.0% (the rated current of the
motor)
Display synchronous motor Magnetic pole angle.
Range: 0.0–360.0
Display synchronous motor phase compensation.
Range: -180.0–180.0
Display synchronous
y Superimposed current.
Range: 0.0%–200.0% (the rated current of the
motor)
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
Display the exciting current reference in the
vector control mode.
Range: -3000.0–3000.0A
motor high-frequency
123
Function parameters
Default
Modify
value
0.00V
●
0.000
●
kHz
0.0%
●
0.0%
●
0.0
●
0m
●
0 ●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A ●
0.0A
●
