INVT Goodrive300 Series Operation Manual page 54

Goodrive300 Series VFD
Function
Name
code
The braking
P01.03 current before
starting
The braking
P01.04 time before
starting
ACC/DEC
P01.05
selection
P01.06 Reserved
P01.07 Reserved
P01.08 Stop mode
Detailed instruction of parameters
state. The starting frequency is not limited in the
lower limit frequency.
Output frequency
fmax
f1
t1
Setting range: 0.0–50.0s
The VFD will carry out DC braking at the braking
current set before starting and it will speed up
after the DC braking time. If the DC braking time
is set to 0, the DC braking is invalid.
The stronger the braking current, the bigger the
braking power. The DC braking current before
starting means the percentage of the rated
current of the VFD.
Setting range of P01.03: 0.0–100.0%
Setting range of P01.04: 0.00–50.00s
The changing mode of the frequency during
start-up and running.
0: Linear type
The output frequency increases or decreases
linearly.
Output frequency
fmax
t1
1: Reserved
0: Decelerate to stop: after the stop command
becomes valid, the VFD decelerates to decrease
the output frequency during the set time. When
the frequency decreases to P01.15, the VFD
stops.
49
f1 set by P01.01
t1 set by P01.02
T
T
t2
Function parameters
Default
Modify
value
0.0%
◎
0.00s
◎
0
◎
Reserved
◎
Reserved
◎
0
○
