INVT Goodrive300 Series Operation Manual page 28

Goodrive300 Series VFD
4.3.1.2 Main circuit connection diagram of VFDs of 3PH 380V (-10%)–550V (+10%)
Single-phase 220V
AC 3PH
380V (-10%)–550V (+10%)
50/60 Hz
Single-phase 220V
AC 3PH
380V (-10%)–550V (+10%)
50/60 Hz
Figure 4-8 Connection diagram of main circuit for the VFDs of 500V
Note:
 The fuse, DC reactor, braking unit, braking resistor, input reactor, input filter, output reactor,
output filter are optional parts. Please refer to Appendix D "Peripherial options and parts" for detailed
information.
 A1 and A2 are optional parts.
P1 and (+) are short circuited in factory for the VFDs of 500V (≥22kW), if need to connect with

the DC rector, please remove the contact tag between P1 and (+).
 Before connecting the braking resistor cable, remove the yellow labels of PB, (+), and (-) from
the terminal blocks. Otherwise, poor connection may occur.
4.3.1.3 Main circuit connection diagram of VFDs of AC 3PH 520V (-15%)–690V (+10%)
520V (-15%)–690V (+10%)
50/60 Hz
Figure 4-9 Connection diagram of main circuit for the VFDs of 660V
Note:
 The fuse, DC reactor, braking unit, braking resistor, input reactor, input filter, output reactor,
A1
(optional)
A2
Input
reactor
Input
filter
Fuse
A1
(optional)
A2
Input
reactor
Input
filter
Fuse
A1
Single-phase 220V
A2
(standard)
Input
reactor
AC 3PH
Input
filter
Fuse
Brake resistor
(+) (-)
PB
R
VFDs (≤18.5 kW)
S
T
Brake unit
DC reactor
DC+
DC-
(+) (-)
P1
R
VFDs (≥22kW)
S
T
Brake unit
DC reactor
DC+
DC-
(-)
P1 (+)
R
VFDs (≥37 kW)
S
T
23
Installation guide
U
Output
reactor
V
Output
W
filter
PE
Brake resistor
U
Output
reactor
V
Output
W filter
PE
Brake resistor
U
Output
reactor
V
Output
W
filter
PE
