INVT Goodrive300 Series Operation Manual page 65

Goodrive300 Series VFD
Function
Name
code
Low switching
P03.02
frequency
Speed loop
P03.03 proportional
gain 2
Speed loop
P03.04
integral time 2
High switching
P03.05
frequency
Speed loop
P03.06
output filter
Compensation
coefficient of
P03.07
electromotion
slip
P03.08 Compensation
Detailed instruction of parameters
parameters are:
parameters are gained according to the linear
change of two groups of parameters. It is shown
as below:
PI parameters
P03.00, P03.01
P03.02
Setting the proportional coefficient and integral
time of the adjustor can change the dynamic
response performance of vector control speed
loop. Increasing the proportional gain and
decreasing the integral time can speed up the
dynamic response of the speed loop. But too high
proportional gain and too low integral time may
cause system vibration and overshoot. Too low
proportional gain may cause system vibration and
speed static deviation.
PI has a close relationship with the inertia of the
system. Adjust on the base of PI according to
different loads to meet various demands.
Setting range of P03.00: 0–200.0
Setting range of P03.01: 0.000–10.000s
Setting range of P03.02: 0.00Hz–P03.05
Setting range of P03.03: 0–200.0
Setting range of P03.04: 0.000–10.000s
Setting range of P03.05: P03.02–P00.03 (Max.
output frequency)
0–8 (corresponds to 0–2
Slip compensation coefficient is used to adjust
the slip frequency of the vector control and
improve the speed control accuracy of the
system. Adjusting the parameter properly can
control the speed steady-state error.
Setting range: 50%–200%
60
P03.03 and P03.04.
P03.03, P03.04
Output frequency
P03.05
8
/10ms)
Function parameters
Default
Modify
value
PI
5.00Hz
○
20.0
○
0.200s
○
10.00
○
Hz
0
○
100%
○
100%
○
