INVT Goodrive300 Series Operation Manual page 173

Goodrive300 Series VFD
Function
code
Terminals control running
P05.13
Switch-on delay of S1
P05.14
Switch-off delay of S1
P05.15
Switch-on delay of S2
P05.16
Switch-off delay of S2
P05.17
Switch-on delay of S3
P05.18
Switch-off delay of S3
P05.19
Switch-on delay of S4
P05.20
Switch-off delay of S4
P05.21
Switch-on delay of S5
P05.22
Switch-off delay of S5
P05.23
Switch-on delay of S6
P05.24
Switch-off delay of S6
P05.25
Name
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
0: 2-wire control 1
1: 2-wire control 2
mode 2: 3-wire control 1
3: 3-wire control 2
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
Detailed instruction of parameters
168
Basic operation instruction
Default
value
0
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
