Goodrive300 Series VFD
Set
value
Switch between A setting and
13
Switch between A setting and
14
combination setting
Switch between B setting and
15
combination setting
16 Multi-step speed terminal 1
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1
22 ACC/DEC time selection 2
23 Simple PLC stop reset
24 Simple PLC pause
Function
B setting
Frequency increasing/decreasing
terminal can cancel the assistant channel frequency
set by the internal UP/DOWN of the VFD to make the
given frequency restore to the frequency given by the
main given frequency channel.
This function can realize the shifting between the
frequency setting channels.
th
The 13 function can realize the shifting between A
frequency given channel and B frequency given
channel.
th
The 14 function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09
th
The 15 function can realize the shifting between B
frequency given channel and the combination setting
channel set by P00.09
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: multi-step speed 1 is the low bit, multi-step
speed 4 is the high bit.
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
terminals.
Terminal Terminal
1 2
OFF OFF
ON OFF
OFF ON
ON ON
Restart simple PLC and clear the memory state of
PLC.
Program pause during PLC implement. Run at the
current speed stage. After cancel the function, simple
164
Basic operation instruction
Instructions
setting
Multi-step
speed 2
BIT1
ACC/DEC time Corresponding
selection
ACC/DEC time 1 P00.11/P00.12
ACC/DEC time 2 P08.00/P08.01
ACC/DEC time 3 P08.02/P08.03
ACC/DEC time 4 P08.04/P08.05
clear
Multi-step
speed 1
BIT0
parameter
