INVT Goodrive300 Series Operation Manual page 171

Goodrive300 Series VFD
Set
value
39 Pre-excitation commands
40 Power consumption clear
41 Power consumption retention
42–60
61 PID pole switching
62–63
Related parameters
Function
code
P05.00
S1 terminals function
P05.01
S2 terminals function
P05.02
S3 terminals function
P05.03
S4 terminals function
P05.04
S5 terminals function
P05.05
S6 terminals function
P05.06
S7 terminals function
P05.07
S8 terminals function
P05.08
HDI terminal function
P05.09
Function
communication
Reversed
Reversed
Name
HDI input selection
selection
selection
selection
selection
selection
selection
selection
selection
selection
command channel will be shifted into communication
running command channel and the running command
channel will come back to the original state if the
function terminal is invalid.
Perform pre-exciting if the terminal is valid until the
terminal is invalid.
The power consumption will be cleared after the
command is valid.
If the command is valid, the current running of the
VFD will not affect its power consumption.
Switch the output pole of PID and be used with
P09.03
Detailed instruction of parameters
0: High pulse input
1: Digital input
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing
(DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
166
Basic operation instruction
Instructions
frequency setting
Default
value
0
1
4
7
0
0
0
0
0
0
