INVT Goodrive300 Series Operation Manual page 224

Goodrive300 Series VFD
Function
instruction
SW 1 of the VFD
SW 2 of the VFD
Address
definition
Special control command word
Bit0–1:=00: motor 1
=10: motor 3
Bit2:=1 torque control prohibit
=0: torque control prohibit invalid
2009H Bit3:=1 power consumption clear
=0:no power consumption clear
Bit4:=1 pre-exciting enabling
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
Virtual input terminal command , range:
200AH
0x000–0x1FF
Virtual output terminal command , range:
200BH
0x00–0x0F
Voltage setting value (special for V/F
200CH separation)
(0–1000, 1000 corresponds to the 100.0%)
AO output setting 1
200DH
(-1000–1000, 1000 corresponds to 100.0%)
AO output setting 2
200EH
(-1000–1000, 1000 corresponds to 100.0%)
0001H:forward running
0002H:forward running
0003H:stop
2100H
0004H:fault
0005H: POFF state
0006H: pre-exciting state
Bit0: =0: not ready for operation =1: ready for
operation
Bi1–2:=00:motor 1
2101H Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5– Bit6: =00: keypad control
Data meaning instruction
=01: motor 2
=11: motor 4
=01:motor 2
=10:motor 3 =11:motor 4
219
Communication protocol
R/W
characteristics
R/W
R/W
R/W
R/W
R/W
R/W
R
R
