INVT Goodrive300 Series Operation Manual page 127

Goodrive300 Series VFD
Function
Name
code
P17.09 Output torque
Evaluated
P17.10 motor
frequency
DC bus
P17.11
voltage
Digital input
P17.12
terminals state
Digital output
P17.13
terminals state
Digital
P17.14
adjustment
Torque
P17.15
reference
P17.16 Linear speed
P17.17 Length
P17.18 Count value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
Detailed instruction of parameters
Display the current output torque of the VFD.
Range: -250.0–250.0%
Evaluate the motor rotor frequency on close loop
vector.
Range: 0.00– P00.03
Display current DC bus voltage of the VFD.
Range: 0.0–2000.0V
Display current Switch input terminals state of the
VFD.
BIT8
HDI
BIT4 BIT3
S5 S4
Range: 0000–01FF
Display current Switch output terminals state of
the VFD.
BIT3 BIT2
RO2 RO1
Range: 0000–000F
Display the adjustment through the keypad of the
VFD.
Range: 0.00Hz–P00.03
Display the torque given, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0%
current of the motor)
Display the current linear speed of the VFD.
Range: 0–65535
Display the current length of the VFD.
Range: 0–65535
Display the current counting number of the VFD.
Range: 0–65535
Display analog AI1 input signal.
Range: 0.00–10.00V
Display analog AI2 input signal.
Range: 0.00–10.00V
122
BIT7 BIT6 BIT5
S8 S7
BIT2 BIT1 BIT0
S3 S2
BIT1 BIT0
HDO
(the
Function parameters
Default
Modify
value
0.0%
0.00Hz
0.0V
S6
0
S1
0
Y
0.00Hz
0.0%
rated
0
0
0
0.00V
0.00V
●
●
●
●
●
●
●
●
●
●
●
●
