INVT Goodrive300 Series Operation Manual page 136

Goodrive300 Series VFD
Function
code
Compensation coefficient
P03.07 of electromotion slip in
Compensation coefficient
P03.08 of braking slip in vector
Current loop proportional
P03.09
Current loop integral
P03.10
P03.11 Torque setting method
P03.12 Keypad setting torque
Torque reference filter
P03.13
P03.14 forward rotation in torque
P03.15 reverse rotation in torque
Name
vector control
control
coefficient P
coefficient I
time
Upper frequency of
control
Upper frequency of
control
Detailed instruction of parameters
50%–200%
50%–200%
0–65535
0–65535
This parameter is used to enable the
torque control mode, and set the torque.
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS/CANopen communication
setting torque
9: Ethernet communication setting torque
10: Reserved
Note: For setting modes of 2–10, 100%
corresponds to three times of the rated
current of the motor.
-300.0%–300.0%
(rated current of the motor)
0.000–10.000s
0: Keypad (P03.16 sets P03.14, P03.17
sets P03.15)
1: AI1
2: AI2
3: AI3
131
Basic operation instruction
Default
value
100%
100%
1000
1000
0
50.0%
0.010s
0
0
