Goodrive300 Series VFD
Function
code
Switch-on delay of S7
P05.26
Switch-off delay of S7
P05.27
Switch-on delay of S8
P05.28
Switch-off delay of S8
P05.29
Switch-on delay of HDI
P05.30
Switch-off delay of HDI
P05.31
Bus voltage at current
P07.39
Digital input terminals
P17.12

7.12 Digital output

Goodrive300 series VFDs have 2 relay output terminals, 1 open collector output terminal Y, and 1
high-speed pulse output terminal (HDO) in the standard configuration. All functions of the digital
output terminals are programmable by using function codes, where the HDO can be set to high-speed
pulse output or switch output through function codes.
Name
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
0.000–50.000s
terminal
fault
state
Detailed instruction of parameters
169
Basic operation instruction
Default
value
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0
0
