Goodrive300 Series VFD
No. Name
Digital
4 potentiom
eter
5 Buttons

5.3 Keypad displaying

The keypad displaying state of Goodrive300 series VFDs is divided into stopping state parameter,
running state parameter, function code parameter editing state and fault alarm state and so on.
5.3.1 Displayed state of stopping parameter
When the VFD is in the stopping state, the keypad will display stopping parameters which is shown in
figure 5-2.
In the stopping state, various kinds of parameters can be displayed. Select the parameters to be
displayed or not by P07.07. See the instructions of P07.07 for the detailed definition of each bit.
In the stopping state, there are 14 stopping parameters can be selected to be displayed or not. They
Tuning frequency. Please refer to P08.41.
Programming key
Entry key
DOWN key
Right-shift key
Reset key
Quick key
Description
Enter or escape from the first level menu
and remove the parameter quickly.
Enter the menu step-by-step
Confirm parameters.
Increase
UP key
progressively.
Decrease
progressively.
Move right to select the displaying
parameter circularly in stopping and
running mode.
Select the parameter modifying digit
during the parameter modification.
This key is used to operate on the VFD in
Run key
key operation mode.
This key is used to stop in running state
Stop/ and it is limited by function code P07.04
This key is used to reset all control modes
in the fault alarm state.
The function of this key is confirmed by
function code P07.02.
36
Keypad operation procedure
data or function
data or function
code
code
