C.1 What this chapter contains
Dimension drawings of the Goodrive300 are shown below. The dimensions are given in millimeters
andinches.
C.2 Keypad structure
C.2.1 Structure chart
7 1 . 3
C.2.2 Installaiton with bracket (optional)
Note: It is necessary to use M3 screw or installation bracket to fix the external keypad. The
installation bracket for VFDs of 380V 1.5–30kW and 500V 4–18.5kW is optional but it is standard for
the VFDs of 380V 37–500kW, 500V 22–500kW and 660V.
Keypad bracket
Installation with bracket for VFDs of 380V 1.5–315kW and 660 V 22–630kW (optional)
160.0
125.0
135.5
4-Φ4.5
106.0
Keypad adapter bracket
Installation with bracket for VFDs of 380V 37–315kW and 660 V 22–630kW (standard)
Appendix C Dimension drawings
3 7 . 1
1 8
8 . 6
Hol e-c utt ing s iz e a nd diagr am f o r non-b rac ke t k eyp ad ins ta llati o n
4-M4×15
(Self-clinching
stud)
81.0 145.5
4-R12
1 9 2 0 . 4
5 8
7 1 . 3
Customer installation demension
108.0 8.5
28.4
81.0
137.5
125.0
Customer installation dimensions
251
Dimension drawings
8.5
108
28.4
125
81
137.5
4-M4×15
(Self-clinching
stud)
4-R13
