Goodrive300 Series VFD
D.4.2.2 AC 3PH 380V(-10%)–550V(+10%)
Model
GD300-004G-5
GD300-5R5G-5
GD300-7R5G-5
GD300-011G-5
GD300-015G-5
GD300-018G-5
GD300-022G-5
GD300-030G-5
GD300-037G-5
GD300-045G-5
GD300-055G-5
GD300-075G-5
Note:
1. Cables of the sizes recommended for the main circuit can be used in scenarios where the ambient
temperature is lower than 40° C, the wiring distance is shorter than 100 m, and the current is the rated
current.
2. The terminals P1, (+), and (-) are used to connect to DC reactors and brake accessories.
D.4.2.3 The VFDs of AC 3PH 520V(-15%)–690V(+10%)
Model
GD300-022G-6
GD300-030G-6
GD300-037G-6
GD300-045G-6
GD300-055G-6
GD300-075G-6
GD300-090G-6
GD300-110G-6
GD300-132G-6
GD300-160G-6
GD300-185G-6
Recommended
2
cable size (mm )
RST
PE
UVW
2.5 2.5
2.5 2.5
2.5 2.5
4 4
6 6
10 10
16 16
16 16
25 16
25 16
35 16
50 25
Recommended
2
cable size (mm )
RST
PE
UVW
10 10
10 10
16 16
16 16
25 16
35 16
35 16
50 25
70 35
95 50
95 50
Connecting cable size (mm
RST PB
P1, (+)
UVW (+),(-)
2.5–6 2.5–6 2.5–6
2.5–6 2.5–6 2.5–6
2.5–6 4–6 4–6
4–16 4–16 4–16
6–16 6–16 6–16
10–16 10–16 10–16
16–50 16–50 16–50
16–50 16–50 16–50
25–50 25–50 25–50
25–50 25–50 25–50
35–50 35–50 35–50
50–95 50–95 50–95
Connecting cable size (mm
RST PB
P1,(+)
UVW (+),(-)
10–16 6–16 6–10
10–16 6–16 6–10
16–25 16–25 6–10
10–16 16–35 10–16
16–25 16–35 16–25
25–50 25–50 25–50
25–50 25–50 25–50
35–95 50–95 25–95
70–95 35–95 50–75
35–95 35–150 25–70 50–150 It is recommended to
35–95 35–150 25–70 50–150
266
Peripherial options and parts
2
)
Tightening
Terminal
torque
screw
PE
2.5–6 M5
2.5–6 M5
2.5–6 M5
4–16 M5
6–16 M5
10–16 M5
16–50 M8
16–50 M8
16–50 M8
16–50 M8
16–50 M8
25–95 M10
2
)
Tightening
Terminal
screw
PE
6–16 M8
6–16 M8
10–16 M8
10–16 M8
16–25 M10
16–25 M10
16–25 M10
25 M10
25–35 M10
use wrench or
(Nm)
2-–2.5
2-–2.5
2-–2.5
2-–2.5
2-–2.5
2-–2.5
9–11
9–11
9–11
9–11
9–11
18–23
torque
(Nm)
9–11
9–11
9–11
9–11
18–23
18–23
18–23
18–23
18–23
