Goodrive300 Series VFD
Function
Name
code
Temporarily
P15.24 variable 1 for
PZD sending
Fault tiem of
P15.25
communicatio
n overtime
Fault tiem of
CANopen
P15.26
communicatio
n overtime
CANopen
P15.27
baud rate
P16 Group Ethernet function
Speed setting
of the Ethernet
P16.00
communicatio
P16.01 IP address 1
P16.02 IP address 2
Detailed instruction of parameters
0–65535
0.0 (invalid),0.1–60.0s
When this function code is set as 0.0, this
function is invalid.
DP When the function code is set as nonzero value, if
the internal
communications exceeds the communication
overtime, the system will report "PROFIBUS
communication fault" (E-DP).
0.0(invalid), 0.1–60.0s
When this function code is set as 0.0, this
function is invalid.
When the function code is set as nonzero value, if
the internal
communication
overtime, the system will report "CANopen
communication fault" (E-CAN).
0: 1000k
1: 800k
2: 500k
3: 250k
4: 125k
5: 100k
6: 50k
7: 20k
0: Self-adapting
1: 100M full duplex
2: 100M semiduplex
3: 10M full duplex
4: 10M semiduplex
n
The function code is used to set the Ethernet
communication speed.
0–255
Set the IP address of Ethernet communication.
time between two
time between two
exceeds the communication
120
Function parameters
Default
Modify
value
0
0.0s
adjent
0.0s
adjent
0
0
192
168
○
○
○
●
◎
◎
◎
