Goodrive300 Series VFD
Function
Name
code
A frequency
P00.06
command
B frequency
P00.07
command
Detailed instruction of parameters
Note: Frequency A and frequency B cannot use
the same frequency setting mode. The frequency
source can be set by P00.09.
0: Keypad
Modify the value P00.10 (set the frequency by
keypad) to modify the frequency by the keypad.
1: AI1
2: AI2
3: AI3
Set the frequency by analog input terminals.
Goodrive300 series VFDs provide 3 ways analog
input terminals as the standard configuration, of
which AI1/AI2 are the voltage/current option
(0–10V/0–20mA) which can be shifted by
jumpers; while AI3 is voltage input (-10V–+10V).
Note: when analog AI1/AI2 select 0–20mA input,
the corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds to
the maximum frequency (function code P00.03) in
forward direction and -100.0% corresponds to the
maximum frequency
(function code P00.03)
4: High-speed pulse HDI setting
The frequency is set by high-speed pulse
terminals. Goodrive300 series VFDs provide 1
high speed pulse input
configuration. The pulse frequency range is
0.00–50.00kHz.
100.0% of the high speed pulse input setting
corresponds to the maximum frequency in
forward direction
corresponds to the maximum frequency in
reverse direction (P00.03).
Note: The pulse setting can only be input by
multi-function terminals HDI. Set P05.00 (HDI
input selection) to high speed pulse input, and set
P05.49 (HDI high speed pulse input function
selection) to frequency setting input.
43
in reverse direction
as the standard
(P00.03) and -100.0%
Function parameters
Default
Modify
value
0
○
2
○
