INVT Goodrive300 Series Operation Manual page 82

Goodrive300 Series VFD
Function
Name
code
of AI3
Corresponding
P05.45 middle setting
of AI3
Upper limit of
P05.46
AI3
Corresponding
setting of
P05.47
the upper limit
of AI3
AI3 input filter
P05.48
time
HDI
high-speed
P05.49 pulse input
function
selection
Lower limit
P05.50 frequency of
HDI
Corresponding
setting of HDI
P05.51
low frequency
setting
Upper limit
P05.52 frequency of
HDI
Corresponding
setting of
P05.53 upper limit
frequency of
HDI
HDI frequency
P05.54
input filter time
Detailed instruction of parameters
Setting range of P05.37: 0.00V–P05.39
Setting range of P05.38: -100.0%–100.0%
Setting range of P05.39: P05.37–10.00V
Setting range of P05.40: -100.0%–100.0%
Setting range of P05.41: 0.000s–10.000s
Setting range of P05.42: -10.00V–P05.44
Setting range of P05.43: -100.0%–100.0%
Setting range of P05.44: P05.42–P05.46
Setting range of P05.45: -100.0%–100.0%
Setting range of P05.46: P05.44–10.00V
Setting range of P05.47: -100.0%–100.0%
Setting range of P05.48: 0.000s–10.000s
The function selection when HDI terminals is
high-speed pulse input
0: Frequency setting input, frequency setting
source
1: Counter input, high-speed pulse counter input
terminals
2: Length counting input, length counter input
terminals
0.000kHz–P05.52
-100.0%–100.0%
P05.50–50.000kHz
-100.0%–100.0%
0.000s–10.000s
77
Function parameters
Default
Modify
value
0.0% ○
10.00V
○
100.0%
○
0.100s
○
0
◎
0.000
○
kHz
0.0%
○
50.000
○
kHz
100.0%
○
0.010s
○
