INVT Goodrive300 Series Operation Manual page 133

Goodrive300 Series VFD
Function
code
P02.02
asynchronous motor 1
P02.03
asynchronous motor 1
P02.04
asynchronous motor 1
P02.05
asynchronous motor 1
P02.15
synchronous motor 1
P02.16
synchronous motor 1
Number of poles pairs for
P02.17
synchronous motor 1
P02.18
synchronous motor 1
P02.19
synchronous motor 1
Multi-function digital input
P05.01–P05
.09 (S1–S8,HDI) function
P07.01
P07.02 QUICK/JOG function
Name
Rated frequency of
Rated speed of
Rated voltage of
Rated current of
Rated power of
Rated frequency of
Rated voltage of
Rated current of
terminals
selection
Parameter copy
Detailed instruction of parameters
0.01Hz–P00.03 (Max. output frequency)
1–36000rpm
0–1200V
0.8–6000.0A
0.1–3000.0kW
0.01Hz–P00.03 (Max. frequency)
1–50
0–1200V
0.8–6000.0A
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
The function code
manner of parameters copy.
0: No operation
1: Upload the local function parameter to
the keypad
2: Download the
parameter to local address (including the
motor parameters)
3: Download the
parameter to local address (excluding the
motor parameter of P02 and P12 group)
4: Download the
parameters to local address (only for the
motor parameter of P02 and P12 group)
0: No function
128
Basic operation instruction
determines the
keypad function
keypad function
keypad function
Default
value
50.00Hz
Depend
on model
Depend
on model
Depend
on model
Depend
on model
50.00Hz
2
Depend
on model
Depend
on model
0
1
