INVT Goodrive300 Series Operation Manual page 156

Goodrive300 Series VFD
Function
code
frequency<lower limit
P01.19
(valid when lower limit>0)
Hibernation restore delay
P01.20
P01.21
Waiting time of restart
P01.22
P01.23
Delay time of the stop
P01.24
P05.01–P05 Digital input function
.09
P08.06
P08.07
P08.08
P08.00
P08.01
P08.02
P08.03
Name
Action if running
frequency
time
Restart after power
outage
after power outage
Start delay time
speed
selection
Jogging frequency
Jogging ACC time
Jogging DEC time
ACC time 2
DEC time 2
ACC time 3
DEC time 3
Detailed instruction of parameters
valid when powering on
0: Run at the lower-limit frequency
1: Stop
2: Hibernation
0.0–3600.0s (valid when P01.19=2)
0: Disable
1: Enable
0.0–3600.0s (valid when P01.21=1)
0.0–60.0s
0.0–100.0s
1: Forward rotation operation
2: Reverse rotation operation
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
21: ACC/DEC time option１
22: ACC/DEC time option２
30: ACC/DEC prohibition
0.00Hz–P00.03 (Max. frequency)
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
0.0–3600.0s
151
Basic operation instruction
Default
value
0
0.0s
0
1.0s
0.0s
0.0s
5.00Hz
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
Depend
on model
