Goodrive300 Series VFD
Function
Name
code
UP terminals
P08.45 frequency
changing ratio
DOWN
terminals
P08.46
frequency
changing ratio
Frequency
P08.47 setting at
power loss
High bit of
P08.48 initial power
consumption
Low bit of
P08.49 initial power
consumption
Magnetic flux
P08.50
braking
Detailed instruction of parameters
LED tens: frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step are priority, it is invalid to
the multi-step
LED hundreds: action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving the
stop commands
0.01–50.00Hz/s
0.01–50.00 Hz/s
0x000–0x111
LED ones: Action selection when power off.
0: Save when power off
1: Clear when power off
LED tens: Action selection when Modbus set
frequency off
0: Save when power off
1: Clear when power off
LED hundreds: The action selection when other
frequency set frequency off
0: Save when power off
1: Clear when power off
This parameter is used to set the original value of
the power comsumotion.
The original value of the power comsumotion
=P08.48×1000+P08.49 (kWh)
Setting range of P08.48: 0–59999 kWh (k)
Setting range of P08.49: 0.0–999.9 kWh
This function code is used to enable magnetic
flux.
96
Function parameters
Default
Modify
value
0.50
○
Hz/s
0.50
○
Hz/s
0x000
○
0 kWh ○
0.0 kWh
○
0
●
