Goodrive300 Series VFD
No. Name
2 Unit LED
Code
3
displaying
zone
LOCAL/REMOT
TRIP
Mean the unit displayed currently
5-figure LED display displays various monitoring data and alarm code such
as set frequency and output frequency.
Displayed Corresponding
character character
Description
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the VFD is in the
keypad operation state; LED blinking
means the VFD is in the terminals
operation state; LED on means the VFD
is in the remote communication control
state.
LED for faults
LED on when the VFD is in the fault state;
LED off in normal state; LED blinking
means the VFD is in the pre-alarm state.
Hz
A
V
RPM
%
Displayed Corresponding
character character
0
3
6
9
C
F
L
O
S
v
35
Keypad operation procedure
Frequency unit
Current unit
Voltage unit
Rotating speed unit
Percentage
Displayed Corresponding
character character
1
4
7
A
d
H
N
P
t
.
2
5
8
b
E
l
n
r
U
-
