INVT Goodrive300 Series Operation Manual page 34

Goodrive300 Series VFD
4. Fasten up all the cables on the outside of the VFD if allowed.
4.3.4 Control circuit wiring diagram
Multi-function input terminal 1
Multi-function input terminal 2
Multi-function input terminal 3
Multi-function input terminal 4
Multi-function input terminal 5
Multi-function input terminal 6
Multi-function input terminal 7
Multi-function input terminal 8
High-speed pulse input collection
Open collector input
–10V
(external)
NG
The screw is
not fastened.
Figure 4-20 Correct installation of the screw
Goodrive300 VFD
S1
S2
S3
S4
S5
S6
S7
S8
HDI
COM
PW
+24V
PE
+10V power supply for setting frequency
AI1
V
AI2
V
AI3 multi-function analog input
GND
PE
Figure 4-21 Control circuit wiring
Y
The screw is
fastened.
Profibus
External
extension card
(optional)
AO1
J1
I
V
DND
AO2
J2
I
V DND
Y1
CME
HDO
CME
485+
J5
485-
GND
PE
RO1A
J3
I
RO1B
J4
RO1C
I
RO2A
RO2B
RO2C
29
Installation guide
Standard
DB9 plug
AO
0–10V/0–20mA
AO
0–10V/0–20mA
Open collector output
High-speed pulse output and
open collector output (optional)
Twisted pairs
Shielding layer
RS485
communication
RO1
RO2
