INVT Goodrive300 Series Operation Manual page 186

Goodrive300 Series VFD
Function
code
P09.03
P09.04 Proportional gain (Kp)
P09.05
P09.06 Differential time (Td)
P09.07
P09.08 PID control deviation limit 0.0–100.0%
P09.09 Output upper limit of PID
P09.10 Output lower limit of PID
P09.11
P09.12
P09.13
Name
PID output feature
Intergal time (Ti)
Sampling cycle (T)
Detection value of
feedback offline
Detection time of
feedback offline
PID adjustment
Detailed instruction of parameters
2: AI3
3: HDI
4: Modbus communication feedback
5: PROFIBUS/CANopen communication
feedback
6: Ethernet communication feedback
7: Reserve
0: PID output is positive
1: PID output is negative
0.00–100.00
0.00–10.00s
0.00–10.00s
0.000–10.000s
P09.10–100.0%
(Max. frequency or the Max. voltage)
-100.0%–P09.09
(Max. frequency or the Max. voltage)
0.0–100.0%
0.0–3600.0s
0x0000–0x1111
LED ones:
0: Keep on integral adjustment when the
frequency achieves the upper and low
limit; the integration shows the change
between the reference and the feedback
unless it reaches the internal integral
limit. When the trend between the
reference and the feedback changes, it
needs more time to offset the impact of
continuous working and the integration
will change with the trend.
1: Stop integral adjustment when the
frequency achieves the upper and low
limit. If the integration keeps stable, and
181
Basic operation instruction
Default
value
0
1.00
0.10s
0.00s
0.100s
0.0%
100.0%
0.0%
0.0%
1.0s
0x0001
