25 PID control pause
Traverse pause (stop at the
26
current frequency)
Traverse reset (return to the
27
middle frequency)
28
29 Torque control disabling
30 ACC/DEC disabling
31
32
33 increasing/decreasing setting
34
Switch between motor1 and
35
36 Switch commands to keypad
Switch commands to
37
38 Switch commands to
Function
Counter reset
Counter trigging
Length reset
Frequency
temporal clear
DC braking
motor2
terminals
PLC continues to run.
Temporal PID invalid and the VFD will output at the
current frequency.
The VFD will stop at the current output and after
canceling the function, the VFD will continue to
traverse run at the current frequency.
The setting frequency of the VFD will come back to
the middle frequency.
Counter clear
The VFD shifts from torque control mode to speed
control mode.
Ensure the VFD will not be affected by the external
signals (except for the stopping command) and keep
the current output frequency.
Enable the pulse counter.
Length counter clear
When the terminal closes, the frequency set by
UP/DOWN can be cleared. All set frequency will be
restored into the given frequency by the frequency
command channel and the frequency will come back
to the value after the frequency increasing or
decreasing.
The VFD will begin DC braking after the valid
command.
Motor-shifting can be controlled after the terminal is
valid.
After the function terminal become valid, the running
command channel will be shifted into keypad running
command channel and the running command channel
will come back to the original state if the function
terminal is invalid.
After the function terminal become valid, the running
command channel will be shifted into terminal running
command channel and the running command channel
will come back to the original state if the function
terminal is invalid.
After the function terminal become valid, the running
