INVT Goodrive300 Series Operation Manual page 56

Goodrive300 Series VFD
Function
Name
code
Shifting
between
P01.14
FWD/REV
rotation
Stopping
P01.15
speed
Detection of
P01.16 stopping
speed
Detection time
of
P01.17
feedback
speed
Terminal
running
P01.18 protection
when
powering on
Detailed instruction of parameters
Output frequency f
Starting
frequency
Setting range: 0.0–3600.0s
Set the threshold point of the VFD:
0: Switch after zero frequency
1: Switch after the starting frequency
2: Switch after the speed reach P01.15 and delay
for P01.24
0.00–100.00Hz
0: Detect according to speed setting (no stopping
delay)
1: Detect according to speed feedback (only valid
for vector control)
If set P01.16 to 1, the feedback frequency is less
than or equal to P01.15 and detect in the set time
of P01.17, the VFD will stop; otherwise the VFD
will stop after the set time of P01.17.
Frequency
Ramp
the
reference
Stop
frequency
speed
Setting range: 0.00–100.00s (only valid when
P01.16=1)
When the running commands are controlled by
the terminal, the system will detect the state of
the running terminal during powering on.
0: The terminal running command is invalid when
powering on. Even the running command is
detected to be valid during powering on, the VFD
Forward
Switch over after
starting frequency
Switch over after
zero frequency
Deadzone
Reverse
time
Output frequency
C
B
A
P01.24 P01.17
Running A
Running B
Running C
51
Function parameters
Default
Modify
value
Time t
0
0.50 Hz
1
0.50s
T
0
◎
◎
◎
◎
○
