INVT Goodrive300 Series Operation Manual page 142

Goodrive300 Series VFD
Function
code
frequency 1 of motor 1
P04.04
voltage 1 of motor 1
P04.05
frequency 2 of motor 1
P04.06
voltage 2 of motor 1
P04.07
frequency 3 of motor 1
P04.08
voltage 3 of motor 1
V/F slip compensation
P04.09
Vibration control factor at
P04.10
low frequency of motor 1
Vibration control factor at
P04.11
high frequency of motor 1
Vibration control threshold
P04.12
P04.13 Motor 2 V/F curve setting
P04.14 Torque boost of motor 2
Torque boost close of
P04.15
P04.16
frequency 1 of motor 2
P04.17
voltage 1 of motor 2
P04.18
frequency 2 of motor 2
P04.19
voltage 2 of motor 2
Name
V/F
V/F
V/F
V/F
V/F
gain of motor 1
of motor 1
motor 2
V/F
V/F
V/F
V/F
Description
0.0%–110.0%
P04.03– P04.07
0.0%–110.0%
P04.05–P02.02 or P04.05–P02.16
0.0%–110.0%
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (Max. output frequency)
0: Straight line V/F curve；applying to the
constant torque load
1: Multi-dots V/F curve
th
2: 1.3 power low torque V/F curve
th
3: 1.7 power low torque V/F curve
th
4: 2.0 power low torque V/F curve
5: Customized V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
0.0%–50.0% (rated frequency of motor 1)
0.00Hz–P04.05
0.0%–110.0%
P04.16– P04.20
0.0%–110.0%
137
Basic operation instruction
Default
value
0.0%
00.00Hz
0.0%
00.00Hz
0.0%
100.0%
10
10
30.00 Hz
0
0.0%
20.0%
0.00Hz
0.0%
0.00Hz
0.0%
