INVT Goodrive300 Series Operation Manual page 116

Goodrive300 Series VFD
Function
Name
code
Magnetic
saturation
P12.13 coefficient 3
for the iron
core of AM2
Magnetic
saturation
P12.14 coefficient 4
for the iron
core of AM2
Rated power
P12.15
synchronous
motor 2
Rated
frequency of
P12.16
synchronous
motor 2
Number of
poles pairs for
P12.17
synchronous
motor 2
Rated voltage
P12.18
synchronous
motor 2
Rated current
P12.19
synchronous
motor 2
Stator resistor
P12.20
synchronous
motor 2
Direct axis
P12.21
inductance of
Detailed instruction of parameters
0.0–100.0%
0.0–100.0%
of
0.1–3000.0kW
0.01Hz–P00.03
(Max. frequency)
1–50
of
0–1200V
of
0.8–6000.0A
of
0.001–65.535Ω
0.01–655.35mH
Set the parameter of the
controlled asynchronous
motor.
In order to ensure
controlling performance, set
the P12.151–P12.19
according to the name plate of
the asynchronous motor.
Goodrive300 series
provide the function
parameter autotuning. Correct
parameter autotuning comes
from the correct setting of the
motor name plate.
In order to ensure
controlling performance,
please configure the motor
according to the standard
principles, if the gap between
the motor and the standard
one is huge, the features of
the VFD will decrease.
Note: Reset the rated power
of the motor
initialize the motor parameter
of P12.16– P12.19.
After finish the
parameter autotuning, the set
111
Function parameters
Default
value
57.0%
40.0%
Depend
on
model
the
50.00
Hz
VFDs
of
2
Depend
on
the
model
Depend
on
model
Depend
on
(P12.15),
model
motor Depend
on
Modify
◎
◎
◎
◎
◎
◎
◎
○
○
