Mii Management Indicators Register - Digi NS7520B-1-C36 Hardware Reference Manual

MII Management Indicators register

Address: FF80 0434
31 30
15 14
Register bit assignment
Bits
D31:03
D02
D01
D00
Table 75: MII Management Indicators register bit definition
29 28 27 26
13 12 11 10
Reserved
Access Mnemonic Reset
N/A Reserved N/A
R NVALID N/A
R SCAN N/A
R BUSY N/A
25 24 23 22 21
Reserved
9 8 7 6 5
Description
N/A
Read data not valid
A 1 indicates that the MII management read cycle is not
complete and read data is not yet valid.
Automatically scan for read data in progress
A 1 indicates that continuous MII management scanning
read operations are in progress.
MII interface BUSY with read/write operation
A 1 indicates that the MII management module is currently
performing an MII management read or write cycle. This
bit returns to 0 when the operation completes.
w w w . d i g i e m b e d d e d . c o m
E t h e r n e t M o d u l e
20 19 18 17 16
4 3 2 1 0
N
SCAN BUSY
VALID
1 9 5
