Bits Access Mnemonic
WAIT[3:0]/BCYC[1:0] continued
D05:04 R/W BSIZE
D03:02 R/W PS
Table 38: Chip Select Option Register A bit definition
M e m o r y C o n t r o l l e r M o d u l e
Reset Description
The first memory cycle of a burst access
follows the timing of a single access. CAS_
is asserted BCYC BCLK cycles for all cycles
that follow the initial cycle in a burst. If
BCYC is set to 0, the controller cannot
execute burst cycles.
When DRSEL=1 and DMODE=10
See "SDRAM," beginning on page 111.
0 Burst access size in beats
00 2 system bus cycles in burst access
01 4 system bus cycles in burst access
10 8 system bus cycles in burst access
11 16 system bus cycles in burst access
Controls the maximum number of memory cycles
that can occur in a burst cycle. This field
determines only the maximum number of
allowable bus cycles; the current bus master can
choose to burst a smaller amount. If the current bus
master continues to burst, the peripheral terminates
the burst when the number of memory cycles
reaches the maximum allowed by this field.
0 for Port size
CS[4:1],
00 32-bit port size
per boot-
01 16-bit port size
strap for
10 8-bit port size
CS0
11 Reserved
Controls the size of the memory peripheral device:
8-, 16-, or 32-bits.
The initial state of PS for CS0 depends on
hardware initialization settings. See "NS7520
bootstrap initialization" on page 59 for more
information.
