Bits Access Mnemonic
D31 R/W ERX
D30 R/W ERXDMA
D29 R/W ERXLNG
D28 R/W ERXSHT
D27 R/W ERXREG
D26 R/W ERFIFOH
D25 R/W ERXBR
D24 R/W ERXBAD
Table 53: Ethernet General Control register bit definition
Reset Description
0 Enable receive FIFO
0 Disables inbound data flow and resets the FIFO
1 Enables inbound data flow
Set to 1 to allow data to be received from the MAC
receiver.
Set to 0 (clear) to reset the receive side FIFO.
0 Enable receive DMA
0 Disables inbound DMA data request
1 Enables inbound DMA data request
Set to 1 to allow the EFE module to issue receive data move
requests to the DMA controller.
Clear this bit to temporarily stall receive side Ethernet
DMA.
0 Accept long (>1520 bytes [MAXF setting]) receive
packets
When set to 1, allows the MAC to accept packets that are
larger than 1520 bytes.
0 Accept short (<60 bytes) receive packets
When set to 1, allows the MAC to accept packets that are
smaller than 60 bytes.
The ERXSHT bit is used primarily for debugging.
0 Enable Receive Data register ready interrupt
Set to 1 to generate an interrupt when data is available in
the RX FIFO.
0 Enable receive data FIFO half full interrupt
Set to 1 to generate an interrupt when the RX FIFO is at
least half full (1024 bytes).
0 Enable receive buffer ready interrupt
Set to 1 to generate an interrupt when a new data packet is
available in the RX FIFO.
0 Accept bad receive packets
When set to 1, allows the MAC to accept packets received
in error. Bad receive packets include those packets with
CRC errors, alignment errors, and dribble errors.
The ERXBAD bit is used primarily for debugging.
