Digi JumpStart Kit Quick Start Manual

1 Verify Kit Contents
Verify that your kit contains one of each of these components:
S2
X18
X24
S4
S7
X27
S6
X16
S3 S5
Development Board
802.11 a/b/g
Antenna
Serial Null Modem Cable
Ethernet Cable
Alternative Power Supply Plugs
Power Supply
3 Connect Hardware to Development Board
a
Connect Serial Port A
Connect Ethernet
b
and/or antennas
Connect to PC
Serial COM Port
Connect VGA cable from
c
VGA monitor (not included
in kit) to VGA port
Add the appropriate plug
d
and connect the power supply.
Do not switch power on.
4 What's Next?
a
Software instructions are on the Welcome page of the CD-ROM.
When the software installation is complete, follow the instructions in
Building Your First Application. This guide introduces you to quickly
creating and running an application in the target platform. Building
Your First Application is accessible from the Start menu group.
