Bits Access Mnemonic
BTE continued
D23 R/W REQ
Table 50: DMA Control register bit definition
Reset Description
The DMA delivers to the destination peripheral the same
number of bytes read from the source peripheral, regardless
of whether the destination peripheral can support bursting.
If the destination peripheral cannot support bursting, the
DMA controller issues multiple bus cycles to complete the
data move.
When operating in memory-to-memory mode, the SIZE
field determines the size of each operand moved. It is
usually more efficient to use a size of 32 bits; different
SIZE values are required, however, when the address
alignment boundaries for the source and destination are
mismatched. If the starting source and destination
boundaries are not on longword boundaries, a size of 16 or
8 bits is required. If the starting source or destination
boundaries are on odd-byte boundaries, a size of 8 bits is
required.
0 Channel request source
0 Internal peripheral
1 External peripheral
Allows DMA channels 3/5 and 4/6 to be attached to either
an internal or external peripheral. When an internal
peripheral is selected, the DMA channel is hardwired to the
peripheral defined in Table 49, "DMA channel
assignments," on page 133.
DMA channels 3/5 interface with an external peripheral
using handshaking signals multiplexed through PORTA.
When REQ is set to 0 in DMA channel 3 and set to 1
in DMA channel 5, DMA channel 5 is tied to the
external DMA port through PORTA.
When REQ is set to 1 in DMA channel 3, that channel
is tied to the external DMA port through PORTA, no
matter the REQ bit setting in DMA channel 5.
