Register bit assignment
Bits
Access
Mnemonic
D31:15
N/A
Reserved
D14
R/W
EDEFER
D13
R/W
BACKP
D12
R/W
NOBO
D11:10
N/A
Reserved
D09
R/W
LONGP
D08
R/W
PUREP
Table 61: MAC Configuration Register 2 bit definition
Reset
Description
N/A
N/A
0
Excess Deferral
1
Allows the MAC to defer to carrier indefinitely, per
the 802.3u standard.
0
The MAC aborts when the excessive deferral limit is
reached. The MAC provides feedback to the host
system (through a transmit abort condition defined in
the Transmit Status register (see "TXAED" on page
170).
0
Backpressure/NO back off
0
After a collision, the MAC waits a random amount of
time to retransmit packets ("back off").
1
After a collision, the MAC immediately retransmits
packets without backoff. This reduces the chance of
further collisions and ensures that transmit packets are
sent.
0
No back off
When this bit is set to 1, the MAC immediately retransmits
after a collision, rather than using the binary exponential
back off algorithm defined in the 802.3u standard.
N/A
N/A
0
Long preamble enforcement
1
The MAC allows only those receive packets that
contain preamble fields less than 12 bytes in length.
0
The MAC allows any length preamble, as defined in
the 802.3u standard.
0
Pure preamble enforcement
1
The MAC verifies the preamble's content to ensure it
contains
'h55
and is error-free. A packet with errors in
the preamble is discarded.
0
There is no preamble checking.
w w w . d i g i e m b e d d e d . c o m
E t h e r n e t M o d u l e
1 7 9
