Summary of Contents for Digi DataFire GO! PRO
- Page 1 Access Resource CD for the DataFire GO! PRO 90000119 A...
- Page 2 Software. You are granted only a limited license to use the Software, and Digi retains all right, title, interest and ownership in and to the Software, which includes all rights arising under the patent, copyright, trade secret or trademark laws of the United States or any foreign jurisdiction.
- Page 3 ASSIGNMENT. You may not assign this license without the prior written consent of Digi. Digi may assign the Software to any third party at its discretion, but will provide you with written notice in the event of such assignment. CHOICE OF LAW AND VENUE. This Software License Agreement shall be governed and construed in accordance with the laws of the State of Minnesota.
- Page 4 Introducing the DataFire GO! PRO Software Key Features ® The DataFire GO! PRO PC Card supports PSTN (K56Flex and ITU-T V.90), Basic Rate ISDN (BRI), GSM(900/1800 Mhz) / PCS(1900 Mhz) cell phone and LAN , which ® ® provides users of Windows 95/98 and Windows NT 4.0 operating systems a wide...
- Page 5 ISDN Switch Support The DataFire GO! PRO PC card will support the following ISDN switch types: Ÿ Euro ISDN (ETSI) NET3 Ÿ National ISDN NI-1 • 5ESS • DMS100 System Requirements The following are system requirements for the DataFire GO! PRO PC Card: Ÿ...
-
Page 6: Before You Begin
Dial-up Networking is installed on your computer. See page 13 for more information. For GSM/PCS connections: Ÿ If you have purchased a DataFire GO! PRO GSM/PCS upgrade kit, you need to determine activation information for GSM/PCS cell phone data connectivity. -
Page 7: Software Installation For Windows 95
Software Installation for Windows 95/98 This procedure describes how to install the DataFire GO! PRO software using the Microsoft Plug & Play system. 1. Shut down the computer. 2. Physically install the PC Card into a PCMCIA slot as shown below. - Page 8 Note: It is important to choose to run the loader program when prompted at the end of the installation. The loader program will download the newly installed programs to the DataFire GO! PRO PC Card to provide complete functionality of all the options you selected to install.
-
Page 9: Software Installation For Windows Nt
This action is required because of limitations in the support that Windows NT 4.0 provides for laptop computers. Please note that because of the limitiations in the operating system, the DataFire GO! PRO may not work in all models of laptop computer. - Page 10 8. Insert the DataFire GO! PRO CD into the drive, then click on OK. Windows NT looks for the drivers available on the disk and displays the name of the driver it finds. 9. Select the PC Card modem then Next.
-
Page 11: Configuring The Devices
Configuring the Devices Depending on the DataFire GO! PRO options you have installed, you may have additional setup tasks to perform. The following software components are available for you to use: For PSTN: Ÿ To access DataFire GO! PRO PSTN modem properties, use the Control Panel Modem icon. -
Page 12: Uninstalling The Software
1. Select Start > Settings > Control Panel > Add/Remove Programs. 2. Select 56K PC Card 3. Click Add/Remove to remove the software. Note: Physically remove the DataFire GO! PRO PC Card if you do not want the system to detect it the next time the system reboots. - Page 13 (Windows 95 Only) Microsoft’s Dial-Up Networking package offers users the ability to make 2 B-Channel 128Kbps Multi-Link PPP ISDN connections. (Please note that your DataFire GO! PRO product is fully capable of making 64Kbps ISDN connections without the upgrade.) 1. Check to see if you have DUN 1.2 or a later release of Dial-Up Networking (DUN 1.2 was the latest when this manual was printed) installed already.
- Page 14 2. Press Next if prompted and then double-click Make New Connection. 3. Next, supply a name for the connection. 4. Select the DataFire GO! PRO PC Card device you intend to use for this connection: Ÿ 56K PC Card Caller ID is used for asynchronous PSTN and GSM/PCS connections.
- Page 15 • SX128 MODEM X75 is used for 64Kbps (1 B-Channel only) ISDN connections with the X75 protocol (i.e. Eurofile transfer protocol). • SX128 MODEM V120 is used for 64Kbps (1 B-Channel only) ISDN connections with the V120 protocol. This is required for Compuserve access. •...
- Page 16 11. Check Use additional devices and then press Add..The Edit Extra Device screen appears: 12. In the Device name field, select the DataFire GO! PRO B-channel (SX128i- Line#1 or SX128i-Line#2) that has not been previously assigned to this connection.
-
Page 17: Regulatory Notices
(2) this device must accept any interference received, including interference that may cause undesired operation. Modifications (FCC 15.21) Changes or modifications to this equipment not expressly approved by Digi may void the user’s authority to operate this equipment. - Page 18 The product listed above has been tested at an External Test Laboratory certified per FCC rules and has been found to meet the FCC, Part 15, Class B, Emission Limits. Documentation is on file and available from the Digi International Homologa- tion Department.
- Page 19 Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper function of your Digi product. If it does, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service.
- Page 20 Equipment Attachment Limitations The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecom- munications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirement documents. The Department does not guarantee that the equipment will operate to the user’s satisfac- tion.
