Digi NS7520B-1-C36 Hardware Reference Manual page 143

Buffer descriptor bit definitions
Bit Description
W Wrap bit.
When set (W=1), tells the DMA controller that this is the last buffer descriptor within the
continuous list of descriptors. The next buffer descriptor is found using the initial DMA
channel buffer descriptor pointer.
When not set (W=0), the next buffer descriptor is found using an offset from the current buffer
descriptor; that is, the DMA channel continues to address buffer descriptors until it finds a
descriptor with W=1 or reaches a 1024-byte boundary.
I When set, tells the DMA controller to issue an interrupt to the CPU when the buffer is closed because
of normal channel completion. The interrupt occurs regardless of the normal completion interrupt
enable configuration for the DMA channel.
L When set, tells the DMA controller that this buffer descriptor is the last descriptor and completes an
entire message frame. The DMA controller uses this bit to signal the peripheral. Use this bit when
multiple descriptors are chained together to form a data frame.
F For fly-by operations, when set, indicates that the buffer is full. A DMA channel sets this bit after
filling a buffer and clears the bit after emptying a buffer. A DMA channel does not try to fill a buffer
when the F bit is set, nor does it try to empty a buffer when the F bit is not set. When the F bit is
modified by firmware, the firmware driver must write to the DMA Status/Interrupt Enable register
to activate an idle DMA channel (see "DMA Status/Interrupt Enable register," beginning on page
142). If a DMA channel encounters a descriptor where F indicates it cannot move data, a maskable
interrupt is generated.
For memory-to-memory operations, the F bit must be set to 1 to begin DMA operation.
Table 47: Buffer descriptor bit definitions
