Digi NS7520B-1-C36 Hardware Reference Manual page 169

Address Register
FF80 0414 MAXF
FF80 0418 SUPP
FF80 041C TEST
FF80 0420 MCFG
FF80 0424 MCMD
FF80 0428 MADR
FF80 042C MWTD
FF80 0430 MRDD
FF80 0434 MIND
FF80 0438 SMII
FF80 0440 SA1
FF80 0444 SA2
FF80 0448 SA3
FF80 05C0 SAFR
FF80 05D0 HT1
FF80 05D4 HT2
FF80 05D8 HT3
FF80 05DC HT4
Table 52: EFE register map
Register description
Maximum Frame register
PHY Support register
Test register
MII Management Configuration register
MII Management Command register
MII Management Address register
MII Management Write Data register
MII Management Read Data register
MII Management Indicators register
SMII Status register
Station Address Register 1
Station Address Register 2
Station Address Register 3
Station Address Filter register
Hash Table Register 1
Hash Table Register 2
Hash Table Register 3
Hash Table Register 4
w w w . d i g i e m b e d d e d . c o m
E t h e r n e t M o d u l e
1 5 7
