Chip select configured for SRAM. The MEM module controls the CS[4:0]_,
OE_, and WE_ signals. The address from the current bus master is driven
directly to A[27:0].
Chip select configured for FP or EDO DRAM. The MEM module can be
programmed to drive a multiplexed address on A[13:0], and drives the
remainder of the address from the current bus master to A[27:14].
–
–
–
Chip select configured for SDRAM. The MEM module can be programmed to
drive a multiplexed address on A[13:0], and drives the remainder of the
address from the current bus master to A[27:14].
–
–
–
–
–
SDRAMs require the DQM function. The BE[3:0]_ signals provides the DQM
function.
MEM module configuration
The MEM module is configured as shown in Table 35. Each chip select contains an
identical set of three registers that appear on a boundary of
Each register is 32 bits unless otherwise noted.
The CS[4:0]_ signals provide the RAS_ function.
The CAS_ signals provide the CAS_ function.
The OE_ and WE_ signals provide the output and write enables,
respectively.
The CS[4:0]_ signals provide the CS[4:0]_ function.
The CAS3_ signal provides the RAS_ function.
The CAS2 function provides the CAS_ function.
The CAS1_ signal provides the WE_ function.
The CAS0_ signal provides the A10/AP multiplexed signal. The A10/AP
multiplexes between the A10 pin for the DRAM and the auto precharge
indicator. The CAS0_ signal must always be connected to the SDRAM A10
pin.
M e m o r y C o n t r o l l e r M o d u l e
bytes.
