Digi NS7520B-1-C36 Hardware Reference Manual page 247

Bits Access Mnemonic
D27 R BGAP
D26 R CGAP
D25:22 N/A Reserved
Table 89: Serial Channel Status Register A bit definition
Reset Description
0 Buffer GAP timer
Set when the enable receive buffer gap timer is set in
Serial Channel Control Register B and the timeout
value defined in the Receive Buffer GAP Timer
register has expired. This bit indicates that the
maximum allowed time has occurred since the first
byte was placed into the receive data buffer. The
receive data buffer is closed under this condition.
When the receiver is configured for DMA, the BGAP
bit is written automatically to the DMA receive buffer
descriptor's status field. When not using DMA,
BGAP is valid only while the RBC bit in this register
is set.
0 Character GAP timer
Set when the enable receive character gap timer is set
in Serial Channel Control Register B and the timeout
value defined in the Receive Character GAP Timer
register has expired. This bit indicates that the
maximum allowed time has occurred since the
previous byte was placed into the receive data buffer.
The receive data buffer is closed under this condition.
When the receiver is configured for DMA, the CGAP
bit is written automatically to the DMA buffer
descriptor's status field. When not using DMA,
CGAP is valid only while the RBC bit is set in this
register.
N/A N/A
w w w . d i g i e m b e d d e d . c o m
S e r i a l C o n t r o l l e r M o d u l e
2 3 5
