- Page 1 All manuals and user guides at all-guides.com SERVICE MANUAL AP-3002AN IEEE 802.11a/b/g/n/ac 2x2 WirelessLAN USB Client AP-3002AN Tentative Edition COPYRIGHT © 2018 DIGI SINGAPORE PTE. LTD.
-
Page 2: Table Of Contents
Safety Regulations ..........................2 1. General ................................5 Model Specification ..........................5 Operating Specification ........................5 2. Enclosure Dimension ............................. 6 3. AP-3002AN Setup Diagram & Procedures....................7 3.1 Setup Diagram ............................7 3.2 Setup Procedures ..........................7 4. Revision Records ............................10... -
Page 3: I) Notice
Screen displays, operating procedures and supporting features might vary with different software version releases. This document shall not be reproduced whether in part or whole without the written consent from DIGI SINGAPORE PTE. LTD. DIGI SINGAPORE PTE. LTD. 4, Leng Kee Road... -
Page 4: Ii) Safety Information
Specifications are subject to change without notice. All dimensions shown are approximate. Please be aware that DIGI has indicated that its hardware and software used in the product may require additional updates in the future as our product is continually under development. The need for such updates most likely applies to the Printer software. -
Page 5: Important Note
All manuals and user guides at all-guides.com Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. - Page 6 IDA Compliance Statement: (Singapore) This equipment registered to comply with IDA (Info-Communications Development Authority of Singapore) Standard under Dealer’s Class License. Contact Information: DIGI America Inc. 76 Veronica Avenu, Somerset, NJ 08873, U.S.A. TEL：+1-732-828-3633 FAX：+1-732-828-4884 For Taiwan 警語：...
-
Page 7: General
All manuals and user guides at all-guides.com AP-3002AN Service Manual 1. General Model Specification Model AP-3002AN Brand Name DIGI Network Standard IEEE 802.11 a/b/g/n/ac compliant Dimensions (in mm) Body Casing 90(L) x 30(W) x 9.5(H) Dimension Color Dark Brown / White 1.5 meters (High Speed USB 3.0 Cable with USB Connector... -
Page 8: Enclosure Dimension
All manuals and user guides at all-guides.com AP-3002AN Service Manual 2. Enclosure Dimension... -
Page 9: Ap-3002An Setup Diagram & Procedures
All manuals and user guides at all-guides.com AP-3002AN Service Manual 3. AP-3002AN Setup Diagram & Procedures 3.1 Setup Diagram Access Point USB Cable connection USB Host PC/Devices AP-3002AN ** Note: ** This equipment is used for professional environment. AP-300AN should be installed and operated with minimum distance 20cm between the radiator &... - Page 10 All manuals and user guides at all-guides.com AP-3002AN Service Manual 2. Attach the AP-3002AN directly into a USB port on your PC. The AP3002AN driver will auto run and install to your PC. A new wireless adapter “Wireless Network Connection” will show.
- Page 11 All manuals and user guides at all-guides.com AP-3002AN Service Manual 4. If you are not able to “enable” your wireless Network Connection, you can “Diagnose” your wireless adaptor, and select “Apply this fix” for resolving the problems. Select “Diagnose” Select “Apply this fix”...
-
Page 12: Revision Records
All manuals and user guides at all-guides.com AP-3002AN Service Manual 4. Revision Records Serial Edition Software Remarks Date Description of Changes Status Version...
