Parameter Description
3.9 Parameters 8-** Communications and
Options
3.9.1 8-0* General Settings
3 3
8-01 Control Site
The setting in this parameter overrides the settings in
parameter 8-50 Coasting Select to parameter 8-56 Preset Reference
Select.
Option:
[0]
*
[1]
[2]
8-02 Control Word Source
Option:
[0] None
[1] FC RS485
[2] FC USB
[3] Option A
*
[4] Option B
[5] Option C0
[6] Option C1
[30] External Can
8-03 Control Timeout Time
Range:
Size [1 -
related 18000 s]
*
100
Function:
Digital and ctrl.word Use both digital input and
control word.
Digital only Use digital inputs only.
Controlword only Use control word only.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the source of the control word: 1 of 2
serial interfaces or 4 installed options. During
initial power-up, the frequency converter
automatically sets this parameter to [3] Option
A if it detects a valid fieldbus option installed
in slot A. If the option is removed, the
frequency converter detects a change in the
configuration, sets parameter 8-02 Control
Source to default setting [1] FC Port, and the
frequency converter then trips. If an option is
installed after initial power-up, the setting of
parameter 8-02 Control Source does not
change, but the frequency converter trips and
shows alarm 67, Option Changed.
Function:
Enter the maximum time expected to pass
between the reception of 2 consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
parameter 8-04 Control Timeout Function is
then carried out. A valid control word
triggers the timeout counter. The minimum
Danfoss A/S © 05/2018 All rights reserved.
®
VLT AQUA Drive FC 202
8-03 Control Timeout Time
Range:
8-04 Control Timeout Function
Select the timeout function. The timeout function is activated
when the control word fails to be updated within the time
period specified in parameter 8-03 Control Timeout Time. [20] N2
Override Release only appears after setting the Metasys N2
protocol.
To change the set-up after a timeout, configure as follows:
1.
2.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
Function:
value that can be set depends on the actual
frequency converter used.
The object list holds information on the
objects that triggers the control timeout:
•
Analog outputs
•
Binary outputs
•
AV0
•
AV1
•
AV2
•
AV4
•
BV1
•
BV2
•
BV3
•
BV4
•
BV5
•
Multistate outputs
Set parameter 0-10 Active Set-up to [9] Multi set-up.
Select the relevant link in parameter 0-12 This Set-up
Linked to.
Function:
Off Resumes control via fieldbus
(fieldbus or standard), using the
most recent control word.
Freeze output Freezes output frequency until
communication resumes.
Stop Stops with auto restart when
communication resumes.
Jogging Runs the motor at jog frequency
until communication resumes.
Max. speed Runs the motor at maximum
frequency until communication
resumes.
Stop and trip Stops the motor, then resets the
frequency converter to restart via:
•
Fieldbus.
•
[Reset].
•
Digital input.
MG20OB02
