Parameter Descriptions
3.10 Parameters: 8-** Communications and
Options
3.10.1 8-0* General Settings
3 3
8-01 Control Site
Option:
[0] Digital and
ctrl.word
[1] Digital only
[2] Controlword
only
8-02 Control Word Source
Option:
[0] None
[1] FC RS485
[2] FC USB
[3] Option A
[4] Option B
[5] Option C0
[6] Option C1
[30] External Can
114
VLT
Function:
The setting in this parameter overrides the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
Control by using both digital input and
control word.
Control by using digital inputs only.
Control by using control word only.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Select the source of the control word: one of
2 serial interfaces or 4 installed options.
During initial power-up, the frequency
converter automatically sets this parameter to
[3] Option A, if it detects a valid fieldbus
option installed in slot A. If the option is
removed, the frequency converter detects a
change in the configuration, sets
parameter 8-02 Control Word Source back to
default setting RS-485, and the frequency
converter trips. If an option is installed after
initial power-up, the setting of
parameter 8-02 Control Word Source does not
change, but the frequency converter trips and
displays: Alarm 67 Option Changed.
When retrofitting a bus option into a
frequency converter that did not have a bus
option installed to begin with, take an ACTIVE
decision to move the control to Bus based.
This is done for safety reasons to avoid an
accidental change.
®
AutomationDrive FC 301/302 Programming Guide
8-03 Control Word Timeout Time
Range:
[1.0 0.1-18000.0 s Enter the maximum time expected to pass
s]
20 s [ 0.1 -
*
18000.0 s]
8-04 Control Word Timeout Function
Select the time-out function. The time-out function activates
when the control word fails to be updated within the time
period specified in 8-03 Control Word Timeout Time.
Option:
[0] Off
[1] Freeze output Freezes output frequency until communi-
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
[7] Select setup 1 Changes the set-up upon reestablishment of
[8] Select setup 2 See [7] Select setup 1
Select setup 3 See [7] Select setup 1
[9]
[10] Select setup 4 See [7] Select setup 1
[26] Trip
MG33MI02 - Rev. 2013-11-20
Function:
between the reception of 2 consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
parameter 8-04 Control Word Timeout
Function is then carried out. A valid control
word triggers the time-out counter.
Enter the maximum time expected to pass
between the reception of 2 consecutive
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
parameter 8-04 Control Word Timeout
Functionis then carried out. A valid control
word triggers the time-out counter.
Function:
Resumes control via serial bus (fieldbus or
standard) using the most recent control
word.
cation resumes.
Stops with auto restart when communi-
cation resumes.
Runs the motor at JOG frequency until
communication resumes.
Runs the motor at maximum frequency until
communication resumes.
Stops the motor, then resets the frequency
converter to restart: via the fieldbus, via
[Reset], or via a digital input.
communication following a control word
time-out. If communication resumes after a
time-out, parameter 8-05 End-of-Timeout
Function defines whether to resume the set-
up used before the time-out, or to retain the
set-up endorsed by the time-out function.
