Parameter Description
18-12 Emergency Mode Log: Date and Time
Range: Function:
Size [ 0 - This parameter contains an array with 10
related 0 ] elements. The parameter shows at which
*
date and time the logged event occurred.
The function relies on the fact that the actual
date and time has been set in
parameter 0-70 Date and Time. Note: There is
no built-in battery back-up of the clock. Use
an external back-up, for example the one in
®
the VLT Analog I/O MCB 109 Analog I/O
option card. See parameter group 0-7* Clock
Settings.
3.16.3 18-3* Analog Readouts
18-30 Analog Input X42/1
Range: Function:
0 [-20 - Readout of the value of the signal applied to
*
20 ]
terminal X42/1 on the VLT
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-00 Terminal X42/1 Mode.
18-31 Analog Input X42/3
Range: Function:
0 [-20 - Readout of the value of the signal applied to
*
20 ]
terminal X42/3 on the VLT
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-01 Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
0 [-20 - Readout of the value of the signal applied to
*
20 ]
terminal X42/5 on the VLT
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-02 Terminal X42/5 Mode.
18-33 Analog Out X42/7 [V]
Range: Function:
0 [0 - 30 ] Readout of the value of the signal applied to
*
terminal X42/7 on the VLT
109.
The value shown reflects the selection in
parameter 26-40 Terminal X42/7 Output.
MG20OB02
Programming Guide
0
0
0
®
analog I/O card MCB
0
®
analog I/O card MCB
0
®
0
analog I/O card MCB
0 SensorlessUnit
®
analog I/O card MCB
Danfoss A/S © 05/2018 All rights reserved.
18-34 Analog Out X42/9 [V]
Range: Function:
[0 - 30 ] Readout of the value of the signal applied to
*
terminal X42/9 on the VLT
109.
The value shown reflects the selection in
parameter 26-50 Terminal X42/9 Output.
18-35 Analog Out X42/11 [V]
Range: Function:
[0 - 30 ] Readout of the value of the signal applied to
*
terminal X42/11 on the VLT
109.
The value shown reflects the selection in
parameter 26-60 Terminal X42/11 Output.
18-36 Analog Input X48/2 [mA]
Range: Function:
[-20 - 20 ] View the actual current measured at input X48/2
*
®
(VLT Sensor Input Card MCB 114).
18-37 Temp. Input X48/4
Range: Function:
[-500 - View the actual temperature measured at input
*
®
500 ]
X48/4 (VLT Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-00 Term. X48/4 Temperature Unit.
18-38 Temp. Input X48/7
Range: Function:
[-500 - View the actual temperature measured at input
*
500 ] ®
X48/7 (VLT Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-02 Term. X48/7 Temperature Unit.
18-39 Temp. Input X48/10
Range: Function:
[-500 - View the actual temperature measured at input
*
500 ] ®
X48/10 (VLT Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-04 Term. X48/10 Temperature Unit.
18-50 Sensorless Readout [unit]
Range:
[-999999.999 - 999999.999
*
SensorlessUnit]
®
analog I/O card MCB
3
®
analog I/O card MCB
Function:
