Parameter Description
13-52 SL Controller Action
Array [20]
Option: Function:
coming from either the digital inputs or
via a fieldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[26] DC Brake Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands
including the coast command stop the
SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0 Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
[30] Start timer 1 Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
[31] Start timer 2 Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
[32] Set digital out A Any output with digital output 1
low selected is low (off).
[33] Set digital out B Any output with digital output 2
low selected is low (off).
[34] Set digital out C Any output with digital output 3
low selected is low (off).
[35] Set digital out D Any output with digital output 4
low selected is low (off).
[36] Set digital out E Any output with digital output 5
low selected is low (off).
[37] Set digital out F Any output with digital output 6
low selected is low (off).
[38] Set digital out A Any output with digital output 1
high selected is high (closed).
[39] Set digital out B Any output with digital output 2
high selected is high (closed).
[40] Set digital out C Any output with digital output 3
high selected is high (closed).
[41] Set digital out D Any output with digital output 4
high selected is high (closed).
MG20OB02
Programming Guide
13-52 SL Controller Action
Array [20]
Option:
[42] Set digital out E
high
[43] Set digital out F
high
[60] Reset Counter A
[61] Reset Counter B
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[80] Sleep Mode
[81] Derag
[82] Reset Derag
Counter
[90] Set ECB Bypass
Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
[101] Reset Flow
Totalized
Volume Counter
[102] Reset Flow
Actual Volume
Counter
