Parameter Description
3.9 Parameters 8-** Communications and
Options
3.9.1 8-0* General Settings
8-01 Control Site
Option: Function:
The setting in this parameter overrides the
settings in parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
[0] Digital and Control by using both digital input and
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
Select the source of the control word: one of
2 serial interfaces or 4 installed options.
During initial power-up, the frequency
converter automatically sets this parameter to
[3] Option A if it detects a valid fieldbus
option installed in slot A. If the option is
removed, the frequency converter detects a
change in the configuration, sets 8-02 Control
Source back to default setting FC Port, and the
frequency converter then trips. If an option is
installed after initial power-up, the setting of
8-02 Control Source does not change, but the
frequency converter trips and displays: Alarm
67 Option Changed.
NOTICE
This parameter cannot be adjusted
while the motor is running.
[0] None
[1] FC Port
[2] USB Port
[3] Option A
[4] Option B
[5] Option C0
[6] Option C1
[30] External Can
8-03 Control Timeout Time
Range: Function:
Size [1 - Enter the maximum time expected to pass
related 18000 s] between the reception of 2 consecutive
*
telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
parameter 8-04 Control Timeout Function
Control Time-out Function is then carried out.
MG20O702
Programming Guide
8-03 Control Timeout Time
Range:
8-04 Control Timeout Function
Option:
[0] Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
[7] Select setup 1
[8] Select setup 2
[9] Select setup 3
[10] Select setup 4
[20] N2 Override
Release
8-05 End-of-Timeout Function
Option:
[0] Hold set-
up
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
In BACnet, the control time-out is only
triggered if some specific objects are written.
The object list hold information on the
objects that triggers the control timeout:
Analog Outputs
Binary Outputs
AV0
AV1
AV2
AV4
BV1
BV2
BV3
BV4
BV5
Multistate Outputs
Function:
Select the time-out function. The time-
out function is activated when the
control word fails to be updated within
the time period specified in
parameter 8-03 Control Timeout Time.
[20] N2 Override Release only appears
after setting the Metasys N2 protocol.
Function:
Select the action after receiving a valid control
word following a time-out. This parameter is
active only when parameter 8-04 Control Timeout
Function is set to [7] Set-up 1, [8] Set-up 2, [9]Set-
up 3 or [10] Set-up 4.
Retains the set-up selected in
parameter 8-04 Control Timeout Function and
displays a warning, until parameter 8-06 Reset
3 3
