Danfoss VLT AQUA Drive FC 202 Programming Manual page 116

Parameter Description
13-01 Start Event
Option:
[20] Alarm (trip)
[21] Alarm (trip lock)
3 3
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18 Use the value of DI18 in the logic rule
[34] Digital input DI19 Use the value of DI19 in the logic rule
[35] Digital input DI27 Use the value of DI27 in the logic rule
[36] Digital input DI29 Use the value of DI29 in the logic rule
[37] Digital input DI32 Use the value of DI32 in the logic rule
[38] Digital input DI33 Use the value of DI33 in the logic rule
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
114
®
VLT AQUA Drive FC 202
Function:
See parameter group 5-3* Digital
Outputs for further description.
See parameter group 5-3* Digital
Outputs for further description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the
logic rule.
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
(High = true).
(High = true).
(High = true).
(High = true).
(High = true).
(High = true).
This event is true if the frequency
converter is started (either via digital
input, fieldbus, or other).
This event is true if the frequency
converter is stopped or coasted (either
via digital input, fieldbus, or other).
This event is true if the frequency
converter is tripped (but not trip-
locked) and [Reset] is pressed.
This event is true if the frequency
converter is tripped (but not trip-
locked) and an automatic reset is
issued.
This event is true if [OK] is pressed.
Danfoss A/S © 05/2018 All rights reserved.
13-01 Start Event
Option: Function:
[44] Reset Key This event is true if [Reset] is pressed.
[45] Left Key This event is true if [◄] is pressed.
[46] Right Key This event is true if [►] is pressed.
[47] Up Key
This event is true if [
[48] Down Key
This event is true if [
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic rule.
[76] Digital input
x30/2
[77] Digital input
x30/3
[78] Digital input
x30/4
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6 See parameter 13-15 RS-FF Operand S,
parameter 13-16 RS-FF Operand R.
[101] RS Flipflop 7
[102] Verifying Flow
[125] Digital input
x46/1
[126] Digital input
x46/3
[127] Digital input
x46/5
[128] Digital input
x46/7
[129] Digital input
x46/9
[130] Digital input
x46/11
[131] Digital input
x46/13
▲
] is pressed.
▼
] is pressed.
