Parameter Lists

4.1.9 8-** Comm. and Options

Param- Parameter description
eter #
8-0* General Settings
8-01 Control Site
8-02 Control Source
4 4
8-03 Control Timeout Time
8-04 Control Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Timeout
8-07 Diagnosis Trigger
8-08 Readout Filtering
8-1* Control Settings
8-10 Control Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
Configurable Alarm and
8-17 Warningword
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity/Stop Bits
8-35 Minimum Response Delay
8-36 Max Response Delay
8-37 Maximum Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram Selection
8-42 PCD Write Configuration
8-43 PCD Read Configuration
8-5* Digital/Bus
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-7* BACnet
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "I-Am" Service
8-75 Initialisation Password
8-8* FC Port Diagnostics
8-80 Bus Message Count
8-81 Bus Error Count
8-82 Slave Message Rcvd
8-83 Slave Error Count
8-9* Bus Jog/Feedback
260
®
VLT AQUA Drive FC 202
Default value 4 set-up
[0] Digital and
ctrl.word All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
[0] Off 1 set-up
[1] Resume set-up 1 set-up
[0] Do not reset All set-ups
[0] Disable 2 set-ups
ExpressionLimit All set-ups
[0] FC profile All set-ups
[1] Profile Default All set-ups
[1] Profile default 2 set-ups
[0] Off All set-ups
[0] FC 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
10 ms 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[1] Standard
telegram 1 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[3] Logic OR All set-ups
[4] Disabled All set-ups
ExpressionLimit All set-ups
[3] Logic OR All set-ups
[0] Digital input All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
1 N/A 1 set-up
127 N/A 1 set-up
1 N/A 1 set-up
[0] Send at power-
up 1 set-up
ExpressionLimit 1 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
Danfoss A/S © 05/2018 All rights reserved.
Change during Conversion
operation index
TRUE -
TRUE -
TRUE -1
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE -3
TRUE -3
TRUE -5
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE 0
TRUE 0
TRUE -
TRUE 0
TRUE 0
TRUE 0
TRUE 0
TRUE 0
Type
Uint8
Uint8
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
Uint8
Uint16
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint32
Uint8
Uint16
Uint8
VisStr[20]
Uint32
Uint32
Uint32
Uint32
MG20OB02
