3.23 Parameters 26-** Analog I/O Option
MCB 109
®
The VLT Analog I/O Option MCB 109 extends the
®
functionality of VLT AQUA Drive FC 202 Series frequency
converters by adding some extra, programmable analog
inputs and outputs. This is useful in control installations
where the frequency converter may be used as decentral
I/O, obviating the need for an outstation and thus reducing
cost. It also provides flexibility in project planning.
NOTICE
The maximum current for the analog outputs 0–10 V is 1
mA.
NOTICE
Where live zero monitoring is used, it is important that
any analog inputs not being used for the frequency
controller, for example being used as part of the building
management system decentral I/O, have their live zero
function disabled.
Terminal
Analog inputs
X42/1
X42/3
X42/5
Analog outputs
X42/7
X42/9
X42/11
Analog inputs
53
54
Analog output
42
Relays
Relay 1, terminals 1, 2, 3.
Relay 2, terminals 4, 5, 6.
Table 3.34 Analog Inputs
MG20OB02
Programming Guide
Parameters
Parameter 26-00 Terminal X42/1
Mode, parameter 26-10 Terminal
X42/1 Low Voltage.
Parameter 26-01 Terminal X42/3
Mode, parameter 26-20 Terminal
X42/3 Low Voltage.
Parameter 26-02 Terminal X42/5
Mode, parameter 26-30 Terminal
X42/5 Low Voltage.
Parameter 26-40 Terminal X42/7
Output.
Parameter 26-50 Terminal X42/9
Output.
Parameter 26-60 Terminal X42/11
Output.
Parameter group 6-1* Analog
Input 1.
Parameter group 6-2* Analog
Input 2.
Parameter group 6-5* Analog
Input 1.
Parameter group 5-4* Relays.
Parameter group 5-4* Relays.
Danfoss A/S © 05/2018 All rights reserved.
It is also possible to read the analog inputs, write to the
analog outputs, and control the relays, using communi-
cation via the fieldbus.
Terminal
Analog inputs (read)
X42/1
X42/3
X42/5
Analog outputs (write)
X42/7
X42/9
X42/11
Analog inputs (read)
53
54
Analog output
42
Relays
Relay 1, terminals 1, 2, 3.
Relay 2, terminals 4, 5, 6.
NOTICE
Enable the relay outputs via control word bit 11 (relay
1) and bit 12 (relay 2).
Table 3.35 Analog Inputs via Fieldbus
On-board real-time clock setting
®
The VLT Analog I/O Option MCB 109 incorporates a real-
time clock with battery back-up. This option can be used
as back-up of the standard clock function included in the
frequency converter. See parameter group 0-7* Clock
Settings.
Use the MCB 109 for control of devices such as actuators
or valves, using the extended closed-loop facility, thus
removing control from the existing control system. See
parameter group 21-** Extended Closed Loop. There are 3
independent closed-loop PID controllers.
Parameters
Parameter 18-30 Analog Input
X42/1.
Parameter 18-31 Analog Input
X42/3.
Parameter 18-32 Analog Input
X42/5.
Parameter 18-33 Analog Out
X42/7 [V].
Parameter 18-34 Analog Out
X42/9 [V].
Parameter 18-35 Analog Out
X42/11 [V].
Parameter 16-62 Analog Input
53.
Parameter 16-64 Analog Input
54.
Parameter 6-63 Terminal X30/8
Output Bus Control.
Parameter 16-71 Relay Output
[bin].
Parameter 16-71 Relay Output
[bin].
