Parameter Description
6. Read power consumption either by looking for
actual power in the data line in the LCP or by
viewing 1 of the following parameters:
6a
3 3
6b
Note the power readout.
7. Program the speeds used in:
7a
7b
7c
7d
8. Program the associated power values in:
8a
8b
8c
8d
9. Switch back with [Auto On] or [Off].
22-30 No-Flow Power
Range:
0 kW [0 - 0 kW] Readout of calculated no-flow power at
*
22-31 Power Correction Factor
Range:
100 % [1 -
400 %]
*
22-32 Low Speed [RPM]
Range:
Size [ 0 - par.
related 22-36
*
RPM]
22-33 Low Speed [Hz]
Range:
Size [ 0 - par.
related 22-37 Hz]
*
182
VLT
Parameter 16-10 Power [kW].
Or
Parameter 16-11 Power [hp] in the Main
Menu.
Parameter 22-32 Low Speed [RPM].
Parameter 22-33 Low Speed [Hz].
Parameter 22-36 High Speed [RPM].
Parameter 22-37 High Speed [Hz].
Parameter 22-34 Low Speed Power [kW].
Parameter 22-35 Low Speed Power [HP].
Parameter 22-38 High Speed Power [kW].
Parameter 22-39 High Speed Power [HP].
Function:
actual speed. If power drops to the display
value, the frequency converter considers the
condition as a no-flow situation.
Function:
Make corrections to the calculated power in
parameter 22-30 No-Flow Power.
If no-flow is detected when it should not be
detected, decrease the setting. However, if no-
flow is not detected when it should be
detected, increase the setting to above 100%.
Function:
To be used if parameter 0-02 Motor Speed
Unit is set to [0] RPM (parameter not
visible if [1] Hz is selected).
Set used speed for the 50% level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
To be used if parameter 0-02 Motor Speed
Unit is set for [1] Hz (parameter not visible
if [0] RPM is selected).
Set used speed for the 50% level.
Danfoss A/S © 05/2018 All rights reserved.
®
AQUA Drive FC 202
22-33 Low Speed [Hz]
Range:
22-34 Low Speed Power [kW]
Range:
Size
related
*
22-35 Low Speed Power [HP]
Range:
Size
related
*
22-36 High Speed [RPM]
Range:
Size
related
*
22-37 High Speed [Hz]
Range:
Size
related
*
22-38 High Speed Power [kW]
Range:
Size
related
*
Function:
The function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-03 Regional
5.50 Settings is set for [0] International
kW] (parameter not visible if [1] North America is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-03 Regional
7.50 hp] Settings is set for [1] North America
(parameter not visible if [0] International is
selected).
Set power consumption at 50% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-02 Motor Speed
par. 4-13 Unit is set for [0] RPM (parameter not
RPM] visible if [1] Hz is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used if parameter 0-02 Motor Speed
par. 4-14 Unit is set for [1] Hz (parameter not visible
Hz] if [0] RPM is selected).
Set used speed for the 85% level.
The function is used for storing values
necessary for tuning no-flow detection.
Function:
[ 0 - To be used, if parameter 0-03 Regional
Settings is set for [0] International
5.50
kW] (parameter not visible if [1] North America is
selected).
Set power consumption at 85% speed level.
This function is used for storing values
necessary for tuning no-flow detection.
