Parameter Description
4-52 Warning Speed Low
Range:
0 RPM [ 0 -
*
par. 4-53
RPM]
3 3
4-53 Warning Speed High
Range:
Size [ par.
related 4-52 -
*
par.
4-13
RPM]
4-54 Warning Reference Low
Range:
-999999.999
*
4-55 Warning Reference High
Range:
999999.999
*
999999.999 ]
74
Function:
Enter the n value. When the motor speed
LOW
drops below this limit (n
LOW
reads Speed Low. The signal outputs can be
programmed to produce a status signal on
terminal 27 or 29, and on relay output 01 or
02. Program the lower signal limit of the
motor speed, n , within the normal
LOW
working range of the frequency converter.
Refer to Illustration 3.27.
Function:
NOTICE
Any changes in parameter 4-13 Motor
Speed High Limit [RPM] reset the value
in parameter 4-53 Warning Speed High
to the same value as set in
parameter 4-13 Motor Speed High Limit
[RPM].
If a different value is needed in
parameter 4-53 Warning Speed High, it
must be set after programming of
parameter 4-13 Motor Speed High Limit
[RPM].
Enter the n value. When the motor speed
HIGH
exceeds this limit (n ), the display reads
HIGH
Speed high. The signal outputs can be
programmed to produce a status signal on
terminal 27 or 29, and on relay output 01 or
02. Program the upper signal limit of the
motor speed, n , within the normal
HIGH
working range of the frequency converter.
Refer to Illustration 3.27.
Function:
[ -999999.999 - Enter the lower reference limit.
par. 4-55 ] When the actual reference drops
below this limit, the display
indicates Ref
Low
outputs can be programmed to
produce a status signal on
terminal 27 or 29, and on relay
output 01 or 02.
Function:
[ par. 4-54 - Enter the upper reference limit.
When the actual reference exceeds
this limit, the display reads Ref
The signal outputs can be
programmed to produce a status
Danfoss A/S © 05/2018 All rights reserved.
®
VLT AQUA Drive FC 202
4-55 Warning Reference High
Range:
), the display
4-56 Warning Feedback Low
Range:
-999999.999
ReferenceFeed-
backUnit
4-57 Warning Feedback High
Range:
999999.999
ReferenceFeed-
backUnit
4-58 Missing Motor Phase Function
Option:
[0] Disabled
*
[1] Trip 100 ms
. The signal
[2] Trip 1000 ms
.
High
Function:
signal on terminal 27 or 29, and
on relay output 01 or 02.
Function:
[ -999999.999 - Enter the lower feedback
par. 4-57 limit. When the feedback
ReferenceFeed- drops below this limit,
*
backUnit] the display reads
Feedb
outputs can be
programmed to produce
a status signal on
terminal 27 or 29, and on
relay output 01 or 02.
Function:
[ par. 4-56 - Enter the upper feedback
999999.999 limit. When the feedback
ReferenceFeed- exceeds this limit, the
*
backUnit] display reads Feedb
The signal outputs can
be programmed to
produce a status signal
on terminal 27 or 29, and
on relay output 01 or 02.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Shows an alarm if a motor phase is missing.
No alarm is shown if a missing motor phase
occurs.
An alarm is shown if a missing motor phase
occurs.
. The signal
Low
.
High
