Parameter Description
3.9 Parameters 8-** Communications and
Options
3.9.1 8-0* General Settings
8-01 Control Site
Option: Function:
The setting in this parameter overrides
the settings in 8-50 Coasting Select to
8-56 Preset Reference Select.
[0] Digital and Control by using both digital input and
*
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword only Control by using control word only.
8-02 Control Source
Option: Function:
Select the source of the control word: one of
two serial interfaces or four installed options.
During initial power-up, the frequency
converter automatically sets this parameter to
[3] Option A if it detects a valid fieldbus
option installed in slot A. If the option is
removed, the frequency converter detects a
change in the configuration, sets 8-02 Control
Source back to default setting FC Port, and the
frequency converter then trips. If an option is
installed after initial power-up, the setting of
8-02 Control Source will not change but the
frequency converter will trip and display:
Alarm 67 Option Changed.
NOTE
This parameter cannot be adjusted while
the motor is running.
[0] None
[1] FC Port
[2] USB Port
[3] Option A
[4] Option B
[5] Option C0
[6] Option C1
[30] External Can
8-03 Control Timeout Time
Range: Function:
Size [1.0 - Enter the maximum time expected to pass
related 18000.0 between the reception of two consecutive
*
s] telegrams. If this time is exceeded, it
indicates that the serial communication has
stopped. The function selected in
8-04 Control Timeout Function Control Time-
out Function will then be carried out.
®
VLT AQUA Drive Programming Guide
8-03 Control Timeout Time
Range:
8-04 Control Timeout Function
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[7]
[8]
[9]
[10] Select setup 4
[20] N2 Override Release
8-05 End-of-Timeout Function
Option:
[0]
®
MG20O602 - VLT is a registered Danfoss trademark
Function:
In BACnet the control timeout is only
triggered if some specific objects are
written. The object list hold information on
the objects that triggers the control
timeout:
Analog Outputs
Binary Outputs
AV0
AV1
AV2
AV4
BV1
BV2
BV3
BV4
BV5
Multistate Outputs
Function:
Select the time-out function. The
time-out function is activated when
the control word fails to be updated
within the time period specified in
8-03 Control Timeout Time. [20] N2
Override Release only appears after
setting the Metasys N2 protocol.
Off
*
Freeze output
Stop
Jogging
Max. speed
Stop and trip
Select setup 1
Select setup 2
Select setup 3
Function:
Select the action after receiving a valid
control word following a time-out. This
parameter is active only when 8-04 Control
Timeout Function is set to [7] Set-up 1, [8] Set-
up 2, [9] Set-up 3 or [10] Set-up 4.
Hold set-up Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
3 3
83
